Taramps DS 800X2 – 2 Ohms Amplifier
$129.99
/
The DS800X2 was designed for anyone who likes to enjoy all frequency ranges with high definition and technology for car audio systems. It is stereo, with a maximum power of 800 Watts RMS and an impedance of 2 Ohms. It has 2 channels of 400 Watts RMS each, or 1 channel connected in BRIDGE with 800 Watts at 4 ohms. The DS 800X2 is FULL RANGE and will certainly play all frequencies the way you like it most.
Technical information
| 2 Ohms VERSION | Nominal Power @12.6VDC 1 Ohm: N/A 2 Ohms: 800W RMS (2 x 400W RMS) 4 Ohms: 500W RMS (2 x 250W RMS) 1 Channel Bridged: 1 x 800W RMS |
|---|---|
| Number of Channels | 02 |
| Input Sensitivity | 250mV |
| Signal to Noise Ratio | >96dB |
| Frequency Response | 10Hz ~ 22KHz (-3dB) |
| Crossover high pass (HPF) | 80Hz ~ 2.2KHz (-6dB/8a) Variable |
| Crossover low pass (LPF) | 80Hz (-12dB/8ª) Fixed |
| Input Impedance | 18K Ohms |
| Output Impedance | 2 Ohms |
| protection system | output overload |
| Minimum Supply Voltage | 9VDC |
| Maximum Supply Voltage | 16VDC |
| Consumption at rest | 0.85A |
| Maximum music consumption | 38A |
| Maximum consumption in sinusoidal signal | 77A |
| Dimensions (WxHxD) | 7.24" x 2.13" x 7.48" (173 x 52 x 227mm) |
| Weight | 3.04lb (1,43kg) |
| EAN | 7898556844048 |
Out of stock
